1550/980nm 2x2 PM Optical Fused Fiber WDM
Description
融合型保偏光纤WDM融合型保偏光纤WDM WDMWDM
主要规格
类型：980/1064；980/1550；1064/1550
工作衰减：±15nm
Max.插入损耗
信号端口 dB 0.8；0.7；0.7
泵端口 dB 0.8；0.7; 0.7
分钟消光比：18分贝; 20分贝; 20分贝
最小值，隔离度：13分贝; 18分贝; 18分贝
最小值方向性：最大55分贝。回波损耗分贝50 。最大值光功率（CW）：3W光纤类型-保偏熊猫光纤封装尺寸 mm φ3*70 φ3*54工作温度 ℃ -5~+75存储温度 ℃ -40~+85对于带连接器的设备，IL高0.3dB，RL低5dB，ER低2dB。对于带连接器的设备，IL 高 0.3dB，RL低 5dB，ER 低 2dB。默认连接键与慢轴同步。方向性：55dBDirectivity: 55dB
有关尺寸和订购信息，请参阅随附的数据表
1550/980nm 2x2 PM Optical Fused Fiber WDM
Specifications |
|
|---|---|
| Operating Wavelength: | 980 nm |
| Operating Bandwidth: | 30 nm |
| Isolation (min): | 13 dB |
| Max Power Handling: | 3 W |
| Polarization Maintaining: | Yes |
Applications
- 高消光比测试仪器
- 高隔离相干通信
- 低注入消耗 EDFAEDFA EDFAEDFA
- 高稳定性和高速度
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
China
-
Sold by:
-
On FindLight:
since 2021
Frequently Asked Questions
The operating bandwidth is ±15nm.
The maximum insertion loss for the signal port is 0.8dB.
The minimum extinction ratio is 18dB.
The maximum directivity is 55dB.
The maximum optical power is 3W.
