Page 8 - Imaging & Spectroscopy

Photonfocus MV1-L2048-96-G2-10 CMOS Camera
Photonfocus AG
The line scan camera series MV1-L2048(I/C)-G2 is based on the CMOSIS CMV2000 CMOS image sensor. The CMOSIS CMV2000 CMOS image sensors are optimized for low light conditions and are available as standard monochrome, as NIR enhanced (I) and as colour (C) versions. The camera series has a line scan mode that allows very high frame ...

Specifications

Sensor Type: CMOS
# Pixels (Width): 2048
# Pixels (Height): 1088
Pixel Size (Square): 5.5 um
Peak Quantum Efficiency: 60 %
Look at the Big Picture The Iris 15 Scientific CMOS camera is designed with a large field of view for live cell microscopy applications. Its 15 megapixel sensor and 25 millimeter field of view provides extremely high-resolution images over a large imaging area. It is the only camera that provides high resolution with video rate ...

Specifications

Sensor Type: sCMOS
# Pixels (Width): 5056
# Pixels (Height): 2968
Pixel Size (Square): 4.25 um
Peak Quantum Efficiency: 73 %
High Resolution BSI Scientific CMOSThe Prime BSI Scientific CMOS camera delivers the perfect balance between high resolution imaging and sensitivity with an optimized pixel design and near perfect 95% Quantum Efficiency to maximize signal detection.A 4 Megapixel camera with 6.5μm pixels, it captures highly ...

Specifications

Sensor Type: sCMOS
# Pixels (Width): 2048
# Pixels (Height): 2048
Pixel Size (Square): 6.5 um
Peak Quantum Efficiency: >95% %
The SynapsePlus FIUV scientific CCD camera is the ideal camera for a variety of spectroscopy applications. Available in a 2048 x 512 chip array format with peak quantum efficiency of 48%, the SynapsePlus FIUV is capable of rapid acquisition speeds, greater than 2200 spectra/s.

Specifications

Sensor Type: CCD
# Pixels (Width): 2048
# Pixels (Height): 512
Pixel Size (Square): 13.5 um
Peak Quantum Efficiency: 48 %
The SynapsePlus OE scientific CCD camera is the ideal camera for a variety of spectroscopy applications. Available in a 1024 x 256 chip array format with peak quantum efficiency of 56%, the SynapsePlus OE is capable of rapid acquisition speeds, greater than 2200 spectra/s.

Specifications

Sensor Type: CCD
# Pixels (Width): 1024
# Pixels (Height): 256
Pixel Size (Square): 26 um
Peak Quantum Efficiency: 59 %
Introducing one of the most sensitive CCD camera platforms in the World. Using a choice of back-illuminated CCD sensor from e2v (CCD42-40 and CCD47-10), and putting into Raptor’s proprietary PentaVac vacuum enclosure and cooling it to -90°C, the Eagle V is the perfect camera for long exposures. Offering low read noise of <2.3e- ...

Specifications

Sensor Type: CCD
# Pixels (Width): 2048
# Pixels (Height): 2048
Pixel Size (Square): 13.5 um
Peak Quantum Efficiency: 90 %
4.2 Megapixel Scientific CMOS Camera Photometrics Prime is the first intelligent scientific CMOS (sCMOS) camera to incorporate a powerful FPGA-based Embedded Signal Processing™ engine (ESP). ESP enables advanced real-time processing features: PrimeEnhance™ quantitatively increases the Peak Signal to Noise Ratio by ...

Specifications

Sensor Type: CMOS, sCMOS
# Pixels (Width): 2048
# Pixels (Height): 2048
Pixel Size (Square): 6.5 um
Peak Quantum Efficiency: 42 %
The CoolSNAP HQ2 Monochrome camera from Photometrics® delivers fast, high-resolution imaging for quantitative fluorescence microscopy applications. This cooled CCD camera provides a large dynamic range with very low noise at both 10 MHz and 20 MHz. The fine pitch of the pixels is ideally matched to the resolution of optical ...

Specifications

Sensor Type: CCD
# Pixels (Width): 1392
# Pixels (Height): 1040
Pixel Size (Square): 6.45 um
Peak Quantum Efficiency: 64 %
The CoolSNAP MYO is a high resolution, high sensitivity camera for moderate to low-light life science applications. This unique cooled CCD provides 4.54μm pixel pitch, 14-bit digitization at 20MHz, enabling high spatial resolution and an optimized frame rate for time-lapse cell imaging. Its 2.8 Megapixels and a high Quantum ...

Specifications

Sensor Type: CCD
# Pixels (Width): 1940
# Pixels (Height): 1460
Pixel Size (Square): 4.54 um
Peak Quantum Efficiency: 75 %
The Photometrics® QuantEM™ 512SC is the world’s first and only electron-multiplying CCD (EMCCD) camera to offer on-chip signal amplification with true quantitative stability across 16 bits at readout rates of 10, 5, and 1.25 MHz. The high-speed, high-performance QuantEM lets you conduct precision ratiometric analysis ...

Specifications

Sensor Type: EMCCD
# Pixels (Width): 512
# Pixels (Height): 512
Pixel Size (Square): 16 um
Peak Quantum Efficiency: 92 %
The new Photometrics Evolve 512 Delta is the ultimate deep-cooled, back-thinned EMCCD camera. Years of engineering expertise have enabled Photometrics to perfect every element of the Evolve 128. The Evolve 128 offers life science researchers the world’s first advanced feature set designed specifically for EMCCD cameras and ...

Specifications

Sensor Type: EMCCD
# Pixels (Width): 512
# Pixels (Height): 512
Pixel Size (Square): 16 um
Peak Quantum Efficiency: 97 %
The Photometrics Evolve 512 is the ultimate deep-cooled, back-thinned EMCCD camera. Years of engineering expertise have enabled Photometrics to perfect every element of the Evolve 512. The Evolve 512 offers life science researchers the world’s first advanced feature set designed specifically for EMCCD cameras and for ...

Specifications

Sensor Type: EMCCD
# Pixels (Width): 512
# Pixels (Height): 512
Pixel Size (Square): 16 um
Peak Quantum Efficiency: 97 %
The Photometrics Evolve 128 is the ultimate deep-cooled, back-thinned EMCCD camera. Years of engineering expertise have enabled Photometrics to perfect every element of the Evolve 128. The Evolve 128 offers life science researchers the world’s first advanced feature set designed specifically for EMCCD cameras and for ...

Specifications

Sensor Type: EMCCD
# Pixels (Width): 128
# Pixels (Height): 128
Pixel Size (Square): 24 um
Peak Quantum Efficiency: 97 %
Andor’s PV Inspector NIR Camera is designed to offer ultimate speed and sensitivity performance for in-line Electro- and Photoluminescence Inspection, delivering > 90% QE beyond 800 nm and incorporating Fringe Suppression Technology™ to minimize fringing effects in the NIR. The 1024 x 1024 array boasts high resolution ...

Specifications

Sensor Type: CCD
# Pixels (Width): 1024
# Pixels (Height): 1024
Pixel Size (Square): 13 um
Peak Quantum Efficiency: 95 %
Andor’s iKon-M 934 series cameras are designed to offer the ultimate in high-sensitivity, low noise performance, ideal for demanding imaging applications. These high resolution 1024 x 1024 CCD cameras boast up to 95% QEmax, high dynamic range, 13 μm pixels and exceptionally low readout noise. The iKon-M benefits from ...

Specifications

Sensor Type: CCD
# Pixels (Width): 1024
# Pixels (Height): 1024
Pixel Size (Square): 13 um
Peak Quantum Efficiency: 95 %
Andor’s iKon-L 936 is designed with scientific imaging in mind. The 2048 x 2048 array and 13.5 x 13.5 μm pixels combine to deliver a 27.6 x 27.6 mm active image area, TE cooled down to -100°C. The iKon-L offers outstanding resolution, field of view, sensitivity and dynamic range performance. Ultimate sensitivity ...

Specifications

Sensor Type: CCD
# Pixels (Width): 2048
# Pixels (Height): 2048
Pixel Size (Square): 13.5 um
Peak Quantum Efficiency: 95 %
The 512 x 512 CCD array with 24 μm pixels has been optimized for the best resolution and dynamic range. It boasts 95% QEmax and exceptionally low readout noise. The iKon-M 912 Cooled Back Illuminated CCD cameras benefit from negligible darkcurrent with industry-leading thermoelectric cooling down to -100°C, enabling ...

Specifications

Sensor Type: CCD
# Pixels (Width): 512
# Pixels (Height): 512
Pixel Size (Square): 24 um
Peak Quantum Efficiency: 95 %
EM technology enables charge from each pixel to be multiplied on the sensor before readout, providing single photon sensitivity. The Newton EM platform combines a 1600 x 200 (or 1600 x 400) array of 16 μm pixels, thermoelectric cooling down to -100°C for negligible dark current, 3MHz readout and USB 2.0 plug-and-play ...

Specifications

Sensor Type: EMCCD
# Pixels (Width): 1600
# Pixels (Height): 400
Pixel Size (Square): 16 um
Peak Quantum Efficiency: 97 %
EM technology enables charge from each pixel to be multiplied on the sensor before readout, providing single photon sensitivity. The Newton EM platform combines a 1600 x 200 (or 1600 x 400) array of 16 μm pixels, thermoelectric cooling down to -100°C for negligible dark current, 3MHz readout and USB 2.0 plug-and-play ...

Specifications

Sensor Type: EMCCD
# Pixels (Width): 1600
# Pixels (Height): 200
Pixel Size (Square): 16 um
Peak Quantum Efficiency: 97 %
This high-end USB2.0 Newton CCD series brings together Andor’s ultra fast, lownoise electronics platform and market-leading deep thermo-electric cooling to -100°C, complemented by Andor’s Ultravac™ technology with its un-matched reliability track record in the scientific and industrial community. Broadband detection rates of up to ...

Specifications

Sensor Type: CCD
# Pixels (Width): 2048
# Pixels (Height): 512
Pixel Size (Square): 13.5 um
Peak Quantum Efficiency: 95 %
