IRC906-SWIR INFRARED CAMERA
Description
With a broad spectral response from 900nm to 2600nm, and the unmatched sensitivity of a cooled InSb sensor, the IRC906 SWIR camera is designed to address the most challenging applications for short wave infrared imagers. More versatile than traditional InGaAs cameras, the extended wavelength response of the IRC906- SWIR makes it indispensable for spectroscopy, infrared search and track, target signature, astronomy, laser detection & characterization, and other demanding SWIR imaging requirements. Based on digital focalplane technology, the 640x512 resolution IRC906 SWIR operates at frame rates of up to 120 Hz with cooled InSb sensitivity, low noise and no pixel crosstalk or blooming.
IRC906-SWIR INFRARED CAMERA
Specifications |
|
|---|---|
| Camera Type: | Industrial, Scientific |
| Array Type: | InSb |
| Spectral Band: | 0.9-5.0um |
| # Pixels (Height): | 640 |
| # Pixels (Width): | 512 |
| Pixel Pitch: | 20 um |
| Array Cooling: | Cooled |
Features
Broad spectral range 900nm - 2600nm
640 x 512 closed-cycle Stirling cooled InSb sensor
120 Hz full window frame rate in full resolution
Motorized four position warm filter wheel option
Simultaneous CameraLink, GigE & HDMI outputs
Optional IRIG and GPS data stamping
Applications
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2019
Frequently Asked Questions
The IRC906 SWIR camera has a broad spectral range of 900nm to 2600nm.
The IRC906 SWIR camera has a resolution of 640x512.
The IRC906 SWIR camera is useful for spectroscopy, infrared search and track, target signature, astronomy, laser detection & characterization, and other demanding SWIR imaging requirements.
The IRC906 SWIR camera features simultaneous 14-bit CameraLink and Gigabit Ethernet digital outputs, along with analog HDMI.
Yes, GPS and IRG-B inputs are available as options for the IRC906 SWIR camera.
