IRC906SLS BROADBAND INFRARED CAMERA
Description
Incorporating an all-digital Strained Layer Superlattice (SLS) focal plane array (FPA), the IRC906SLS detects infrared radiation in both the mid-wave (MWIR) and long-wave (LWIR) spectral regions. It’s like having two cameras in one - an optional embedded warm filter wheel allows the user to select specific wavelengths of interest in both the MWIR and LWIR regions, taking full advantage of the broadband response of the SLS sensor. This 640 x 512 format, 20 micron pixel pitch scientific camera runs at up to 475 frames per second with no electronic crosstalk. Full rate image data is available via Camera Link; simultaneous Gigabit Ethernet (GigE) and HDMI outputs are also offered.
IRC906SLS BROADBAND INFRARED CAMERA
Specifications |
|
|---|---|
| Camera Type: | Industrial, Scientific |
| Array Type: | InSb |
| Spectral Band: | 2.0-11.25um |
| # Pixels (Height): | 640 |
| # Pixels (Width): | 512 |
| Pixel Pitch: | 20 um |
| Array Cooling: | Cooled |
Features
640 x 512 closed-cycle cooled SLS sensor
2.0 μm to 11.25 μm spectral response
NEdT < 35 mK at full frame rate
475 Hz full window frame rate
Motorized four position warm filter wheel optional
Simultaneous CameraLink, GigE & HDMI outputs
Applications
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2019
Frequently Asked Questions
The IRC906SLS is a scientific camera that detects infrared radiation in both the mid-wave (MWIR) and long-wave (LWIR) spectral regions.
The IRC906SLS has a spectral response of 2.0 μm to 11.25 μm.
The IRC906SLS has a full window frame rate of up to 475 frames per second with no electronic crosstalk.
The IRC906SLS offers simultaneous CameraLink, Gigabit Ethernet (GigE), and HDMI outputs.
The IRC906SLS is well suited for spectroscopy, chemical analysis, target signature detection and characterization, and material evaluation applications.
