ZEPHIR 2.9 - SWIR camera 850-2900 nm
Description
The ZephIR 2.9 is a deep-cooled, extended SWIR camera sensitive from 850 to 2900 nm. By deep-cooling the infrared sensor, the ZephIR 2.9 is able to acquire more signals and minimize unwanted noise for a given imaging application. The extended spectral range offers scientists and engineers the possibility of acquiring a signal covering a broader wavelength spectrum, which in turn helps build better infrared detection systems. By using thermoelectric cooling, the ZephIR 2.9 doesn’t require any maintenance from a water or a liquid nitrogen chilled unit and does not suffer from the limited lifetime of Stirling mechanical coolers. This leads to greater usability and flexibility when integrating ZephIR 2.9 cameras in your own systems.
With high frame rates allowing high speed image acquisitions through USB 3.0 or cameralink, the ZephIR 2.9 is tailored for demanding industrial applications or high precision scientific experiments. Users can also choose to use Photon etc’s PHySpec camera control software or develop their own using a Python or C++ software development kit (SDK). Perfect capabilities for the detection of various black plastics and carbonates for the mining sector.
ZEPHIR 2.9 - SWIR camera 850-2900 nm
Specifications |
|
|---|---|
| Camera Type: | Industrial, Scientific |
| Array Type: | Mercury Cadmium Telluride (MCT, HgCdTe) |
| Spectral Band: | 0.85-2.9um |
| # Pixels (Height): | 320 |
| # Pixels (Width): | 256 |
| Pixel Pitch: | 30 um |
| Array Cooling: | Cooled |
| Cooling: | TEC 4 stages, forced air |
| Weight: | 2.6 kg |
| Frame Rate: | 340 |
| Dark Current: | 160 Mē/px/s |
| Readout Noise: | 165 ē |
| Digitization: | 14 bits |
| Computer Interface: | CameraLink™ or USB 3.0 |
| Physical Dimensions: | 169 x 130 x 97.25 mm |
| Weight: | 2.9 kg |
Features
The SWIR camera hardware includes coded region-of-interest (ROI), which allows the operator to select between a full-frame rate of 340 frames per second (fps) and a windowed rate of up to 3000 fps.
Additionally, it comes with Photon etc’s PHySpec camera control software or an extensive software development kit (SDK) for developing your own custom software.
Applications
The ZEPHIR 2.9 SWIR camera is ideal for :
quality control,
industrial sorting,
sciences,
astronomy, and
spectroscopy.
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
Canada
-
Sold by:
-
On FindLight:
since 2015
Frequently Asked Questions
The spectral range of ZephIR 2.9 SWIR camera is 850-2900 nm.
ZephIR 2.9 SWIR camera has a frame rate of up to 340 frames per second.
ZephIR 2.9 SWIR camera uses a 4-stage thermoelectric cooler (TEC) with forced air heat dissipation to maintain low temperatures.
ZephIR 2.9 SWIR camera has found applications in mining, quality control, waste sorting, and hyperspectral imaging.
Users can use Photon etc’s PHySpec camera control software or develop their own using an extensive software development kit (SDK) to control ZephIR 2.9 SWIR camera.
