Green Laser Module,532nm, Dot or Line, 30mW,50mW,100mW
Description
Green Laser Module-Dot
Features:
Crystal-growing experience for 15years
Cost effective
High stability and reliability
Applications:
Laser pointer
Laser stage lights
Outdoor lawn lights
Specifications:
Items Parameters
Part No. LMGD-30/50/100
Wavelength (nm) 532+/-1nm
Transverse Mode Tem00
Output Power >30-100mW
Working Voltage 2V
Working Current 380-500mA
Beam Size (10m) <18mm
Housing Material Copper or Aluminum alloy
Operating Temperature 10~40®C
Storage Temperature -40 ~+70®C
Expected Lifetime >5000hrs
Warranty Period 6 months
Dimension D13*L30mm
Note: 1. Customized Sizes available upon request.
Green Laser Module,532nm, Dot or Line, 30mW,50mW,100mW
Specifications |
|
|---|---|
| Wavelength: | 532nm |
| Output Power: | 30-100mW |
| Dimension: | D13*30 and others |
Features
Red Laser Module-635nm
Features:
Manufacturing experience for 15 years
Cost effective
High stability and reliability
Applications:
Industrial Marker
Military instruments and equipment
Experimental Light Source
Laser aiming
Specifications:
Items Parameters
Part No. LMRD-635-07/15
Wavelength (nm) 635+/-10nm
Line Power >7-15mW
Input Voltage 3.0-5.0V
Input Current <30-60mA
Beam Size (100m) <70mm
Housing Material Copper or Aluminum Alloy
Operating Temperature -20~+65®C
Storage Temperature -40 ~+80®C
Expected Lifetime >5000hrs
Warranty Period 6 months
Dimension D7*L33mm
Note: 1. Customized Sizes available upon request.
Applications
Green Laser Module-Line
Features:
Crystal-growing experience for 15 years
Cost effective
High stability and reliability
Applications:
Laser Level Gauge
Marble cutting Positioning
Machinery Positioning
Specifications:
Items Parameters
Part No. LMGL-10/20
Wavelength (nm) 532+/-1nm
Line Power 10-20mW (+/-2mW )
Input Voltage DC 3.7V
Input Current <250mA
Line Width (5m) <2mm
Divergence Angle 120®
Housing Material Aluminum alloy
Operating Temperature 0~45®C
Storage Temperature -40 ~+70®C
Expected Lifetime >5000hrs
Warranty Period 6 months
Dimension D15*L30mm
Note: 1. Customized Sizes available upon request.
