LED Drivers for Peak Performance

iC-HG 200 MHz Laser Switch
IC-Haus GmbH
As a specialist for mixed-signal integrated circuits and system-on-chip solutions, iC-Haus has been designing and manufacturing application-specific standard products (ASSPs) and custom ASICs for more than 35 years. We supply industrial, medical, and automotive applications with innovative, reliable, and FMEA-approved integrated ...

Specifications

Frequency Range: 200000-200000KHz
Minimum Pulse Duration: -- us
Power Output: N/A
Input Voltage: N/A
Output Voltage: N/A
UXYR LED-Pulse-Controller: Your Solution for High-Speed LED Illumination
LEJ
Discover the UXYR LED-Pulse-Controller, a revolutionary tool designed to provide full parameter control for high-power LEDs and LED groups. This advanced controller offers 2 or 4 independent constant current outputs, ensuring the lowest overshoot and highest pulse stability for your lighting systems. With an output current of up to ...

Specifications

Frequency Range: 1-200KHz
Minimum Pulse Duration: 1 us
Power Output: <10W
Input Voltage: Other
Output Voltage: <10V
Model 5500A Series Multi-channel High Current LED Driver/Controller
Innovations in Optics
The 5500A common cathode LED driver by Innovations in Optics provides independent control of 18 high power LED channels. Unique to this application, each channel is powered by an individual high efficiency, constant current switch mode power supply capable of 3A continuous output. The 5500A has been specially designed to ensure ...

Specifications

Frequency Range: 1-15KHz
Minimum Pulse Duration: 20 us
Power Output: 10W-20W
Input Voltage: Other
Output Voltage: <10V
DCS Controller with Triple Output Channels for LED Illumination
Advanced illumination
The DCS Controller Triple Output is an advanced LED lighting controller that allows for the independent control of up to three lighting channels. It features both constant current and constant voltage modes of operation, making it compatible with a wide range of LED lights. The DCS Controller Triple Output is designed to be easy to ...

Specifications

Frequency Range: 2-2KHz
Minimum Pulse Duration: 30 us
Controller Style: Discrete Control System (External, Detachable)
User Interface: Software GUI, Web Browser
Operating Modes: Pulse (Overdrive Strobe), Gated Continuous, Continuous
LED12W-D Switch Mode LED Drivers
Hubbell Lighting Components
12W LED Drivers with 0-10V dimming. Constant Current, Dimming with Isolation.

Specifications

Frequency Range: 0.05-0.06KHz
Minimum Pulse Duration: -- us
Input Voltage Range:: 277 V
Power Factor: >0.90
Inrush Current: <10.0 Amps
Laser Diode Driver SF350
FEDAL
Switched mode laser power supply is designed for supplying diode array, which are used for pumping powerful solid or fiber lasers. Power supply is designed to the laboratory, educational, experimental and industrial applications. Additionally the power supply can be equipped with a LD thermal stabilization controller (TEC ...

Specifications

Frequency Range: 0.001-1KHz
Minimum Pulse Duration: 50 us
Laser Diode Driver SF315
FEDAL
Switched mode laser power supply is designed for supplying diode array, which are used for pumping powerful solid or fiber lasers. Power supply is designed to the laboratory, educational, experimental and industrial applications. Additionally the power supply can be equipped with a LD thermal stabilization controller (TEC ...

Specifications

Frequency Range: 0.001-0.5KHz
Minimum Pulse Duration: 50 us
Laser Diode Driver SF306
FEDAL
Switched mode laser power supply is designed for supplying diode array, which are used for pumping powerful solid or fiber lasers. Power supply is designed to the laboratory, educational, experimental and industrial applications. Additionally the power supply can be equipped with a LD thermal stabilization controller (TEC ...

Specifications

Frequency Range: 0.001-0.5KHz
Minimum Pulse Duration: 50 us
LED12W Switch Mode LED Drivers
Hubbell Lighting Components
12W fixed-output LED Drivers. Constant Current & Constant Voltage models. Includes isolation on output.

Specifications

Frequency Range: 0.05-0.06KHz
Minimum Pulse Duration: -- us
LED17W Switch Mode LED Drivers
Hubbell Lighting Components
17W LED Drivers. Constant Current & Constant Voltage models. Universal 100-27Vac input.

Specifications

Frequency Range: 0.05-0.06KHz
Minimum Pulse Duration: -- us
iC-HG30 250 MHz Laser Switch
IC-Haus GmbH
As a specialist for mixed-signal integrated circuits and system-on-chip solutions, iC-Haus has been designing and manufacturing application-specific standard products (ASSPs) and custom ASICs for more than 35 years. We supply industrial, medical, and automotive applications with innovative, reliable, and FMEA-approved integrated ...

Specifications

Frequency Range: 250000-250000KHz
Minimum Pulse Duration: -- us
iC-HGP 200 MHz High-Side Laser Switch
IC-Haus GmbH
As a specialist for mixed-signal integrated circuits and system-on-chip solutions, iC-Haus has been designing and manufacturing application-specific standard products (ASSPs) and custom ASICs for more than 35 years. We supply industrial, medical, and automotive applications with innovative, reliable, and FMEA-approved integrated ...

Specifications

Frequency Range: 200000-200000KHz
Minimum Pulse Duration: -- us
M09001 LED Driver
Macom
The M09001 is a highly integrated, high efficiency driver and power management IC designed for LCoS/TI DLP® enabled displays. It provides three SPI or I2C programmable 1.2A LED/laser drivers with >90% efficient buck-boost converter, power management functionalities, including high voltage generators for DMD and LCoS panels. ...

Specifications

Frequency Range: 1-1KHz
Minimum Pulse Duration: -- us
M09000 LED Driver
Macom
The M09000 is a highly integrated, high efficiency driver and power management IC designed for LCoS/TI DLP® enabled displays. It provides three SPI or I2C programmable 1.2A LED/laser drivers with >90% efficient buck-boost converter, power management functionalities, including high voltage generators for DMD and LCoS panels. ...

Specifications

Frequency Range: 1-1KHz
Minimum Pulse Duration: -- us
M08980 LED Driver
Macom
The M08980 is a highly integrated, high efficiency driver and power management IC designed for LCoS/TI DLP® enabled displays. It provides three SPI or I2C programmable 1.2A LED/laser drivers with >90% efficient buck-boost converter, power management functionalities, including high voltage generators for DMD and LCoS panels. ...

Specifications

Frequency Range: 1-1KHz
Minimum Pulse Duration: -- us
M08889 High-Performance 2A RGB LED/Laser Driver
Macom
The M08889 is a high efficiency three channel 2 A LED/laser driver with integrated buck-boost synchronous DC-DC converter for panel based projection displays. It features automatic optical power control for consistent white balance across temperature variation and light sources aging. The internal buck-boost DC-DC converter ...

Specifications

Frequency Range: 1-1KHz
Minimum Pulse Duration: 1 us
M08888 High-Performance 2A RGB LED/Laser Driver
Macom
The M08888 is a high efficiency integrated triple channel 2A LED/laser driver for LCD/LCoS/TI DLP® projection displays. It features automatic optical power control for consistent white balance across temperature variation and light source aging. The M08888 allows for the control of an external DC-DC converter to generate optimal ...

Specifications

Frequency Range: 1-1KHz
Minimum Pulse Duration: 1 us
M08886 High-Performance RGB LED/Laser Driver
Macom
The M08886 is a high efficiency integrated RGB LED/Laser driver with patent pending de-speckle and power save technologies for panel based projection displays. It features ColorMinder - a multilevel automatic laser power control for consistent white balance across temperature variation and laser aging. The M08886 allows for the ...

Specifications

Frequency Range: 1-1KHz
Minimum Pulse Duration: - us
Aurora DR Driver/Controller
Innovations in Optics
The Aurora DR LineSource drivers & controllers incorporate fully integrated power solutions and Automatic Device Sensing.

Specifications

Frequency Range: 1-15KHz
Minimum Pulse Duration: -- us

Frequently Asked Questions

An LED driver serves as a power supply for LED lights, converting high voltage, alternating current (AC) into low voltage, direct current (DC). It ensures the LED's longevity and performance by regulating the power supplied.

LED drivers are essential as they provide the specific electrical conditions required by LEDs to function optimally. They deliver a constant power output to protect against power fluctuations, which can damage or reduce the performance of LEDs.

LED drivers help maximize the energy efficiency of LEDs by providing the right amount of power needed for the LED. This way, they ensure that energy is used efficiently, reducing waste and lowering operational costs.

LED drivers are versatile and can be used in various applications including residential, commercial, and industrial lighting solutions. They are chosen based on the unique power requirements of each LED application.

Choosing the right LED driver involves understanding the power requirements of your LED light, the intended application, and specific environmental conditions. Consider factors like the driver's power output, efficiency, lifespan, size, and IP rating.

By providing a consistent and suitable power supply, LED drivers prevent premature LED failure and ensure consistent lighting quality. This contributes significantly to extending the lifespan of the LEDs.

Understanding LED Drivers

LED drivers serve a crucial role in the functionality of light-emitting diodes (LEDs). As specialized power supplies, they convert high voltage, alternating current (AC) into low voltage, direct current (DC). Their importance lies in maintaining the longevity and efficiency of LED lights, enhancing their performance by regulating the power supplied.

The Vital Role of LED Drivers in Lighting

LED technology has taken center stage in the lighting industry due to its superior energy efficiency, longevity, and overall performance. But these advanced lighting solutions require specific electrical characteristics to function optimally, and that's the role LED drivers play. By delivering a constant power output, LED drivers protect against fluctuations in input power that could potentially damage or degrade LED lights' performance.

Regulating Power to Ensure LED Longevity

LED drivers are the heart of LED lighting systems, controlling the power that gets to the LEDs. They regulate the power to match the specific requirements of the LED, providing a stable current despite varying voltage conditions. This function prevents premature LED failure and ensures consistent lighting quality.

The Efficiency of LED Drivers

Efficiency is a significant consideration in the choice of lighting solutions. LED drivers help maximize the potential of LEDs by providing the right amount of power to the LED. This functionality ensures energy is utilized efficiently, reducing energy waste and lowering operational costs.

The Versatility of LED Drivers

One of the remarkable aspects of LED drivers is their versatility. They can be tailored to suit different applications, including residential lighting, commercial lighting, and industrial lighting solutions. By understanding the unique power requirements of each LED application, you can select the right LED driver that ensures optimal performance and durability.

Choosing the Right LED Driver

Choosing the right LED driver involves considering the power requirements of your LED light, the intended application, and any specific environmental conditions. Some factors to consider include the driver's power output, efficiency, lifespan, size, and IP rating.

Conclusion: The Value of LED Drivers

In conclusion, LED drivers are more than just power supplies; they are the key to unlocking the full potential of LED technology. By ensuring a stable power supply and optimizing energy use, they enable LEDs to provide consistent, efficient, and long-lasting lighting solutions. Whether for residential, commercial, or industrial applications, LED drivers play an integral part in delivering high-quality, reliable, and efficient lighting.

Did You know?

The impressive performance and energy efficiency of LED lights largely depend on a vital component: the LED driver. This unsung hero converts high voltage, alternating current (AC) into low voltage, direct current (DC), providing a constant power supply that is crucial for optimal LED performance. Without LED drivers, your LED lights are susceptible to damage from power fluctuations. Furthermore, LED drivers play a significant role in extending the life of your LEDs by regulating the power delivered, thus avoiding overloading or shortening the LED lifespan. Whether for residential, commercial, or industrial applications, the choice of the right LED driver is essential to unlocking the full potential of your LED lighting solutions. Next time you marvel at the performance of an LED light, remember the critical role played by the LED driver!
