1.0um High Power Single Frequency Polarization Maintaining Fiber Amplifier
Description
MARS series high power single frequency polarization maintaining fiber amplifiers by Connet are designed specifically for ultra-narrow linewidth single frequency laser sources, such as the fiber lasers based on the principle of Distributed Feedback Bragg Grating (DFB) or Distributed Bragg Reflector (DBR).
This kind of a fiber amplifier has the capability of boosting the low power optical signal at kHz frequencies up to 100W output power while preserving the spectral properties of the input signal. MARS series amplifiers use the high power, high-performance, multi-mode pumps internally, employ the technology of double cladding fiber amplification, and have the integrated design in a polarization-maintaining structure. These high power single frequency fiber amplifiers come with a continuously tunable output power.
With the extensive experience in handling the double cladding fiber, Connet conducts proper optimal design for the high power polarization maintaining fiber amplifiers to achieve the high efficiency output and suppress the nonlinear effects of the fiber. The unique thermal treatment technology guarantees that the benchtop fiber amplifier can be operated stably for a long time.
In order to ensure the safety of the whole system, the high-speed response protection circuit monitors the power of the input and output signals automatically so that it can cut down the operation of the high power pump in case of the input signal fall-off.
MARS series fiber amplifiers are turn-key user-friendly systems with a microprocessor inside for laser control purposes. The front panel is equipped with a switch to start the laser, a LCD to display the state of the power and a knob to adjust the output power.
1.0um High Power Single Frequency Polarization Maintaining Fiber Amplifier
Specifications |
|
|---|---|
| Amplifier Type: | YDFA - Ytterbium-Doped Fiber Amplifier |
| Wavelength Range: | 1040-1090nm |
| Min Input Power: | 0 dBm |
| Max Output Power: | 47 dBm |
| Nominal Gain: | -- dB |
| Output Fiber Type: | PM980, PLMA |
| Dimensions: | 19” 2U / 3U |
| Cooling Mode: | Air-Cooling |
| Storage Temperature: | -40~+ 85 ℃ |
| Operating Temperature: | 0~+30 ℃ |
| Power Supply: | 100~240 VAC |
| Optical Connector: | FC/APC or Collimator (other optional) |
| Input Fiber Type: | PM980 |
| Beam Quality (M2): | ≤1,2 |
| Output Power Stability (8hrs): | ≤±2 % |
| Polarization Extinction Ratio: | ≥17 dB |
| Output Power Tunable Range: | 10~100 % |
| Optical Signal Noise Ratio (OSNR): | ≥50 dB |
| Output Isolation: | ≥30 dB |
| Input Isolation: | ≥30 dB |
| Polarization: | Linear Polarization |
Features
This high power single frequency polarization maintaining fiber amplifier module exhibit various features, such as:
- High output power: 100W
- Low noise figure
- Turn-key and user-friendly system
- Polarization maintaining fiber structure, high PER
- High stability, high reliability
Applications
Connet MARS series high power benchtop polarization-maintaining fiber amplifiers can be widely used in scientific research, coherent beam combining, coherent detection, fiber sensing system, etc. Key applications include:
- Coherent detection
- Coherent combining
- Atomic cooling and trapping
- Fiber sensing
- Frequency doubling
Applications in other areas are also possible. We will support your requests and try to meet the needs of your specific application.
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
China
-
Sold by:
-
On FindLight:
since 2016
Frequently Asked Questions
The amplifier is designed to boost low power optical signals at kHz frequencies up to 100W output power while preserving the spectral properties of the input signal.
This amplifier is compatible with ultra-narrow linewidth single frequency laser sources, such as fiber lasers based on the principle of Distributed Feedback Bragg Grating (DFB) or Distributed Bragg Reflector (DBR).
The features of the amplifier include high output power (up to 100W), low noise figure, turn-key and user-friendly system, polarization maintaining fiber structure with high PER, and high stability and reliability.
The amplifier can be used in scientific research, coherent beam combining, coherent detection, fiber sensing systems, and more. Key applications include coherent detection, coherent combining, atomic cooling and trapping, fiber sensing, and frequency doubling.
The amplifier has a high-speed response protection circuit that monitors the power of the input and output signals automatically. It can cut down the operation of the high power pump in case of the input signal fall-off to ensure the safety of the whole system.
