Description

The OEM series of sealed CO₂ laser sources, comprising OEM 45iX, OEM 65iX and OEM 100iX, can operate over a wide range of pulse widths and frequencies including safe operation through the acoustic regions and over a broad range of coolant temperatures. A compact solution that can be easily integrated into industrial processing production lines, the OEM series can be sited in confined spaces in any orientation both with or without covers.

OEM 45iX CO₂ Laser

Visit the Luxinar Ltd Store

Specifications

Gas Medium: CO2
Wavelength: 9.3 um
Output Power: 400 W
Mode Quality (M^2): <1.2
Beam Diameter: 11 mm
Beam Divergence (Full Angle): 2 mrad
Polarization: Linear
Cooling: Water-to-Water

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

OEM 45iX – 450W sealed CO₂ laser source

Power output up to 450W

IP56 rating
Wavelengths 10.6µm, 10.25µm, 9.3µm
Short optical pulse with high peak power or quasi-CW output
Minimum shipment power 20% higher than rated power
The OEM series of CO₂ lasers represents a compact solution that can be easily integrated into industrial processing production lines. The OEM 45iX includes an integrated RF power supply, enabling the laser to produce short optical pulses with high peak power or quasi-CW output. There is also the option for an absorbing thin film reflector (ATFR) to prevent back reflection issues.

The OEM series lasers use a single resonator design, producing laser light with a linear polarisation. With a beam quality of K > 0.8, power and precision are defining characteristics of these lasers. Since many equipment manufacturers purchase this range to integrate into their equipment, these OEM iX laser sources are available without the laser housing, if desired.

Applications

  • Cutting
  • Drilling
  • Marking
  • Engraving
  • Scribing
  • Perforating
  • Welding
  • Kiss Cutting

Frequently Asked Questions

What are some of the applications of the OEM 45iX CO₂ laser source?
Some of the applications of the OEM 45iX CO₂ laser source include cutting, drilling, marking, engraving, scribing, perforating, welding, and kiss cutting.
What is the beam quality factor of the OEM 45iX CO₂ laser source?
The beam quality factor of the OEM 45iX CO₂ laser source is M2 < 1.2 (K > 0.83).
What is the IP rating of the OEM 45iX CO₂ laser source?
The IP rating of the OEM 45iX CO₂ laser source is IP56.
What is the power output of the OEM 45iX CO₂ laser source?
The power output of the OEM 45iX CO₂ laser source is up to 450W.
What is the wavelength range of the OEM series of CO₂ lasers?
The wavelength range of the OEM series of CO₂ lasers is 10.6µm, 10.25µm, and 9.3µm.

Got more questions? Use the inquiry form to ask the supplier directly.
