Description
Maiman Laser 532nm 20W DPSS Green Laser Source MMEPG-532-20-HE-D70 for Cutting of CVD Diamond and Natrial Diamond
- With ultra-high cost performance can meet 7*24 hours manufacturing
- Stone Plus series· more robust performance
- More adaptable to complex and harsh environments
For more details, click Maiman Laser532nm 20Watt DPSS Green Laser
Maiman Laser 532nm 20W DPSS Green Laser Source MMEPG-532-20-HE-D70 for Diamond Cutting
Tianjin Maiman Laser Technology Co., Ltd
Specifications |
|
|---|---|
| Avg. Power: | 20 W |
| Wavelength: | 532 nm |
| Repetition Rate: | 7-100kHz |
| Spatial Mode (M^2): | 1.5 |
| Pulse Duration: | 70 ns |
| Pulse-to-Pulse Stability (RMS): | 3 % |
| Cooling: | Water-to-Water |
| Single Pulse Energy (uJ): | 2000 uJ |
| Beam Diameter: | ~0.9 mm |
| Long Term Stability: | <±3% |
| Polarization Ratio: | Vertical;>100:1 |
Features
- The laser power 20W, single pulse energy＞2mj, superior beam quality M² <1.5
- Solve power attenuation and meet 7*24 hours of work
- The service life exceeds 20,000 hours maintenance-free, ultra-long service life and power stability
- All-in-one design, build-in power supply, Q-switch drive and TEC
- Excellent beam quality M < 1.5, easy operate and higher efficiency
- 3 layers of protection, protection grade IP65,·more suitable for harsh working environment
Applications
- SiC Wafer Scribing
- Diamond Cutting-Slicing and Coring
- Carbon material cutting
- Cutting of super hard materials - PcBN, PCD, SCD, CVD, SiC, etc
