MPL-N-355 DPSS Laser
Scitec Instruments Ltd.
Add to watch list
MPL-N-355 DPSS Laser
Compare
All solid state 355nm UV laser is made features of ultra compact, long lifetime, cost-effectiveness and easy operating, which is widely used in UV curing, micro-electronics, CD carving, laser medical treatment, scientific experiments, etc.

Specifications
Avg. Power: 0.8 W
Wavelength: 355 nm
Repetition Rate: 10-15kHz
Spatial Mode (M^2): N/A
Pulse Duration: 7 ns
Data Sheet
Inquire Price
MPL-N-266 DPSS Laser
Scitec Instruments Ltd.
Add to watch list
MPL-N-266 DPSS Laser
Compare
All solid state 266nm UV laser is made features of ultra compact, long lifetime, cost-effectiveness and easy operating, which is widely used in UV curing, micro-electronics, CD carving, laser medical treatment, scientific experiments, etc.

Specifications
Avg. Power: 0.12 W
Wavelength: 266 nm
Repetition Rate: 10-15kHz
Spatial Mode (M^2): N/A
Pulse Duration: 6 ns
Data Sheet
Inquire Price
MPL-N-257 DPSS Laser
Scitec Instruments Ltd.
Add to watch list
MPL-N-257 DPSS Laser
Compare
All solid state 257nm UV laser is made features of ultra compact, long lifetime, cost-effectiveness and easy operating, which is widely used in UV curing, micro-electronics, CD carving, laser medical treatment, scientific experiments, etc.

Specifications
Avg. Power: 0.015 W
Wavelength: 257 nm
Repetition Rate: 10-15kHz
Spatial Mode (M^2): N/A
Pulse Duration: 10 ns
Data Sheet
Inquire Price
AO-W-266 DPSS Laser
Scitec Instruments Ltd.
Add to watch list
AO-W-266 DPSS Laser
Compare
All solid state AOM Q-switched laser at 266 nm has the features of high peak power, high repetition rate, and short pulse duration, which is widely used in marking, measure, carving, research and so on.

Specifications
Avg. Power: 0.2 W
Wavelength: 266 nm
Repetition Rate: 1-50kHz
Spatial Mode (M^2): N/A
Pulse Duration: 15 ns
Data Sheet
Inquire Price
AO-V-355 DPSS Laser
Scitec Instruments Ltd.
Add to watch list
AO-V-355 DPSS Laser
Compare
All solid state AOM Q-switched laser at 355 nm has the features of high peak power, high repetition rate, and short pulse duration, which is widely used in scientific research, Biology, Instrumentation, 3D marking, laser marking, sub-surface engraving and so on.

Specifications
Avg. Power: 3 W
Wavelength: 355 nm
Repetition Rate: 10-100kHz
Spatial Mode (M^2): N/A
Pulse Duration: 15 ns
Data Sheet
Inquire Price
LEO 15 DPSS Laser
Photon Energy GmbH
Add to watch list
LEO 15 DPSS Laser
Compare
LEO 15: laser head with laser control unit

Specifications
Avg. Power: 15 W
Wavelength: 1064 nm
Repetition Rate: 1-100kHz
Spatial Mode (M^2): N/A
Pulse Duration: N/A ns
Data Sheet
Inquire Price
LEO 8 DPSS Laser
Photon Energy GmbH
Add to watch list
LEO 8 DPSS Laser
Compare
LEO 8: laser head with laser control unit

Specifications
Avg. Power: 8 W
Wavelength: 1064 nm
Repetition Rate: 1-100kHz
Spatial Mode (M^2): N/A
Pulse Duration: N/A ns
Data Sheet
Inquire Price
NL204 Q-switched DPSS Nanosecond Laser
EKSPLA
Add to watch list
NL204 Q-switched DPSS Nanosecond Laser
Compare
NL200 series DPSS Q-switched nanosecond lasers offer high pulse energy at kHz repetition rates. End-pumped design makes this laser compact and easy to integrate. Harmonic generation modules for 532 nm, 355 nm, 266 nm and 213 nm wavelengths are easily attached to the laser frame. Featuring short pulse duration, variable repetition ...

Specifications
Avg. Power: 4 W
Wavelength: 1064 nm
Repetition Rate: 0.5-1kHz
Spatial Mode (M^2): 1.3
Pulse Duration: 10 ns
Data Sheet
Inquire Price
NL202 Q-switched DPSS Nanosecond Laser
EKSPLA
Add to watch list
NL202 Q-switched DPSS Nanosecond Laser
Compare
NL200 series DPSS Q-switched nanosecond lasers offer high pulse energy at kHz repetition rates. End-pumped design makes this laser compact and easy to integrate. Harmonic generation modules for 532 nm, 355 nm, 266 nm and 213 nm wavelengths are easily attached to the laser frame. Featuring short pulse duration, variable repetition ...

Specifications
Avg. Power: 2 W
Wavelength: 1064 nm
Repetition Rate: 0.01-1kHz
Spatial Mode (M^2): 1.3
Pulse Duration: 10 ns
Data Sheet
Inquire Price
NL201 Q-switched DPSS Nanosecond Laser
EKSPLA
Add to watch list
NL201 Q-switched DPSS Nanosecond Laser
Compare
NL200 series DPSS Q-switched nanosecond lasers offer high pulse energy at kHz repetition rates. End-pumped design makes this laser compact and easy to integrate. Harmonic generation modules for 532 nm, 355 nm, 266 nm and 213 nm wavelengths are easily attached to the laser frame. Featuring short pulse duration, variable repetition ...

Specifications
Avg. Power: 2.2 W
Wavelength: 1064 nm
Repetition Rate: 0.01-2.5kHz
Spatial Mode (M^2): 1.3
Pulse Duration: 10 ns
Data Sheet
Inquire Price
Myron-20-0 Diode-Pumped Q-Switched Nd:YAG Green Laser
UpTek Solutions
Add to watch list
Myron-20-0 Diode-Pumped Q-Switched Nd:YAG Green Laser
Compare
The Myron is a diode-pumped, Q-switched second harmonic Nd:YAG laser. It features a field-proven long-life diode module and no DI water requirement for water chiller. The rugged enclosure design, optimized cavity design and PRF adjustment result in excellent output stability over a large, dynamic range as well as increased ...

Specifications
Avg. Power: 20 W
Wavelength: 532 nm
Repetition Rate: 1-20kHz
Spatial Mode (M^2): 1.2
Pulse Duration: 90 ns
Data Sheet
Inquire Price
Myron-30-M Diode-Pumped Q-Switched Nd:YAG Green Laser
UpTek Solutions
Add to watch list
Myron-30-M Diode-Pumped Q-Switched Nd:YAG Green Laser
Compare
The Myron is a diode-pumped, Q-switched second harmonic Nd:YAG laser. It features a field-proven long-life diode module and no DI water requirement for water chiller. The rugged enclosure design, optimized cavity design and PRF adjustment result in excellent output stability over a large, dynamic range as well as increased ...

Specifications
Avg. Power: 30 W
Wavelength: 532 nm
Repetition Rate: 1-20kHz
Spatial Mode (M^2): 10
Pulse Duration: 120 ns
Data Sheet
Inquire Price
Lucia-45-M Diode-Pumped Q-Switched Nd:YLF Green Laser
UpTek Solutions
Add to watch list
Lucia-45-M Diode-Pumped Q-Switched Nd:YLF Green Laser
Compare
The Lucia series are diode-pumped, Q-switched second harmonic Nd:YLF lasers. They feature field-proven longlife diode module and no DI water requirement for water chiller. The rugged enclosure design and optimum cavity design result in excellent output stability as well as increased reliability for long-term operation. The Lucia ...

Specifications
Avg. Power: 30 W
Wavelength: 527 nm
Repetition Rate: 1-10kHz
Spatial Mode (M^2): 1.6
Pulse Duration: 300 ns
Data Sheet
Inquire Price
Lucia-30-M Diode-Pumped Q-Switched Nd:YLF Green Laser
UpTek Solutions
Add to watch list
Lucia-30-M Diode-Pumped Q-Switched Nd:YLF Green Laser
Compare
The Lucia series are diode-pumped, Q-switched second harmonic Nd:YLF lasers. They feature field-proven longlife diode module and no DI water requirement for water chiller. The rugged enclosure design and optimum cavity design result in excellent output stability as well as increased reliability for long-term operation. The Lucia ...

Specifications
Avg. Power: 20 W
Wavelength: 527 nm
Repetition Rate: 1-10kHz
Spatial Mode (M^2): 1.6
Pulse Duration: 200 ns
Data Sheet
Inquire Price
HIGH PULSE ENERGY AIR-COOLED DPSS Nd:YAG LASER QX500
SOLAR Laser Systems
Add to watch list
HIGH PULSE ENERGY AIR-COOLED DPSS Nd:YAG LASER QX500
Compare
SOLAR LS presents a new model of completely air-cooled pulsed diode-pumped Nd:YAG laser. The QX500 delivers 160 mJ at 1064 nm in nanosecond pulses at repetition rates up to 20 Hz. The QX500 laser features long-life laser diode bars and delivers excellent pulse-to-pulse and long-term stability which is ideally suited for use in ...

Specifications
Avg. Power: 3.2 W
Wavelength: 1064 nm
Repetition Rate: 0.02-0.02kHz
Spatial Mode (M^2): N/A
Pulse Duration: 10 ns
Data Sheet
Inquire Price
QC140 ULTRACOMPACT Q-SWITCHED MICROCHIP LASER
SOLAR Laser Systems
Add to watch list
QC140 ULTRACOMPACT Q-SWITCHED MICROCHIP LASER
Compare
SOLAR LS offers a family of passive Q-switched microlasers. The QC series lasers are diode-pumped solid-state lasers operating at 1540 nm and 1064 nm 532 nm, 355 nm, 266 nm.Non-misalignable monolithic cavity guarantees reliability of operation and extreme stability of laser parameters. Pulse duration of ~1 ns ensures high peak power ...

Specifications
Avg. Power: 0.06 W
Wavelength: 266 nm
Repetition Rate: 0.1-0.3kHz
Spatial Mode (M^2): 1.5
Pulse Duration: 0.9 ns
Data Sheet
Inquire Price
QC130 ULTRACOMPACT Q-SWITCHED MICROCHIP LASER
SOLAR Laser Systems
Add to watch list
QC130 ULTRACOMPACT Q-SWITCHED MICROCHIP LASER
Compare
SOLAR LS offers a family of passive Q-switched microlasers. The QC series lasers are diode-pumped solid-state lasers operating at 1540 nm and 1064 nm 532 nm, 355 nm, 266 nm.Non-misalignable monolithic cavity guarantees reliability of operation and extreme stability of laser parameters. Pulse duration of ~1 ns ensures high peak power ...

Specifications
Avg. Power: 0.1 W
Wavelength: 355 nm
Repetition Rate: 0.1-0.3kHz
Spatial Mode (M^2): 1.5
Pulse Duration: 0.9 ns
Data Sheet
Inquire Price
QC120 ULTRACOMPACT Q-SWITCHED MICROCHIP LASER
SOLAR Laser Systems
Add to watch list
QC120 ULTRACOMPACT Q-SWITCHED MICROCHIP LASER
Compare
SOLAR LS offers a family of passive Q-switched microlasers. The QC series lasers are diode-pumped solid-state lasers operating at 1540 nm and 1064 nm 532 nm, 355 nm, 266 nm.Non-misalignable monolithic cavity guarantees reliability of operation and extreme stability of laser parameters. Pulse duration of ~1 ns ensures high peak power ...

Specifications
Avg. Power: 0.2 W
Wavelength: 532 nm
Repetition Rate: 0.1-0.3kHz
Spatial Mode (M^2): 1.5
Pulse Duration: 0.9 ns
Data Sheet
Inquire Price
QC110 ULTRACOMPACT Q-SWITCHED MICROCHIP LASER
SOLAR Laser Systems
Add to watch list
QC110 ULTRACOMPACT Q-SWITCHED MICROCHIP LASER
Compare
SOLAR LS offers a family of passive Q-switched microlasers. The QC series lasers are diode-pumped solid-state lasers operating at 1540 nm and 1064 nm 532 nm, 355 nm, 266 nm. Non-misalignable monolithic cavity guarantees reliability of operation and extreme stability of laser parameters. Pulse duration of ~1 ns ensures high peak power ...

Specifications
Avg. Power: 0.4 W
Wavelength: 1064 nm
Repetition Rate: 0.1-0.3kHz
Spatial Mode (M^2): 1.5
Pulse Duration: 0.9 ns
Data Sheet
Inquire Price
JX330 COMPACT AIR-COOLED kHz DPSS LASER
SOLAR Laser Systems
Add to watch list
JX330 COMPACT AIR-COOLED kHz DPSS LASER
Compare
Diode-pumped lasers of the JX300 series have a number of unique design features ensuring their failure-free and stable operation in a wide range of environmental conditions. Unpretentiousness to operating conditions and excellent beam quality will satisfy both scientists performing fine scientific experiments and industrial sector ...

Specifications
Avg. Power: 3 W
Wavelength: 355 nm
Repetition Rate: 1-100kHz
Spatial Mode (M^2): 1.2
Pulse Duration: 16 ns
Data Sheet
Inquire Price
