PRONTO-3K Portable Laser Power Meter
Description
The PRONTO-3K is a portable laser power meter designed to measure laser power with precision, catering to applications with power levels of up to 3,000 W. This compact and versatile device provides quick and accurate measurements with a minimal exposure time of 10 seconds.
It operates within a broad spectral range from 0.193 to 20 μm, ensuring compatibility with various laser sources. With ±5% power calibration uncertainty, the PRONTO-3K is a reliable tool for professionals in laser-related fields.
PRONTO-3K Portable Laser Power Meter
Specifications |
|
|---|---|
| Max Average Power: | 3000 W |
| Effective Aperture: | 55 mm |
| Spectral Range: | 0.19-20um |
| Cooling Method: | Convection |
| Minimum Average Power: | 5.0 W |
| Noise Equivalent Power: | 5.0 W |
| Response Time: | 10 s |
| Maximum Average Power Density: | 7 kW/cm² |
| Maximum Allowable Casing Temperature: | 65 °C |
| Battery Type: | Rechargeable Li-ion |
| Battery Life: | 17 hours or 4,200 measurements (with brightness set at 25%) |
| Display Resolution: | 4 digits |
| Display Size: | 28.0 x 35.0 mm (128 x 160 pixels) |
| Display Type: | Touch Screen Color LCD |
| Backlight: | Adjustable |
| Internet Upgrades Via: | USB |
| Data Storage: | 50,000 pts |
| Battery Recharge Via: | USB |
| Absorber: | H |
| Dimensions: | 88W x 88L x 43D |
| Weight: | 1.24 kg |
| Mounting Holes: | 1 x 8-32, 2 x 1/4-20 |
Features
- Power Range: Measures laser power up to 3,000 W
- Quick Measurements: Provides results in as little as 10 seconds
- Broad Spectral Range: Operates in the spectral range of 0.193 - 20 μm
- Calibration Accuracy: Ensures ±5% power calibration uncertainty
- Compact and Portable: Designed for easy portability and on-site measurements
- Continuous Power Mode: Allows for continuous power monitoring
- Damage Thresholds: Equipped with high damage thresholds for durability
- User-Friendly Interface: Designed with a straightforward GUI
Applications
- Suitable for professionals working with lasers up to 3,000 W
- Ideal for a wide range of laser power measurement applications
- Quick measurements with minimal exposure time
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
Canada
-
Sold by:
-
On FindLight:
since 2014
Frequently Asked Questions
The PRONTO-3K High Power Probes have a power range of 1 W - 3,000 W.
The PRONTO-3K High Power Probes use convection for cooling.
The response time for the PRONTO-3K High Power Probes is 10 seconds.
Yes, you can save your data to the internal memory and transfer it to your PC over the USB connection.
The maximum allowable absorber temperature for the PRONTO-3K High Power Probes is 75 °C.
