VUV-UV Notch - Reflective Filter 220nm M220-3045-1D (1.0" Diameter)
Description
Teledyne Acton Optics presents VUV/UV Notch - Reflective Filters, advanced all-dielectric reflectors designed for 45-degree angle of incidence (AOI). These filters offer exceptionally high reflectance at specific VUV through UV wavelengths while transmitting longer-wavelength UV-to-IR light.
Custom UV filters catering to peak wavelengths >250 nm are available, ensuring DUV-VUV transmittance below ~210 nm. Coatings can be applied to Acton standard substrates, custom substrates, and customer-supplied materials.
VUV-UV Notch - Reflective Filter 220nm M220-3045-1D (1.0" Diameter)
Specifications |
|
|---|---|
| Diameter: | 25.4 mm |
| Thickness: | 2.5 mm |
| Center Wavelength: | 220 nm |
| Full Width-Half Max (FWHM): | 25 nm |
| Transmission Wavelength Range: | -----nm |
| Transmission: | -- % |
| Reflection @ Center Wavelength: | ≥ 90 % |
Features
- High Reflectance: Reflects specific VUV through UV wavelengths with peak reflectance ranging from 40% to 90%
- Broad Range: Covers wavelengths from 126 nm to 360 nm, providing comprehensive coverage for various applications
- Customization: Offers customization for filters with peak wavelengths above 250 nm, ensuring tailored solutions
- All-Dielectric Design: Utilizes advanced all-dielectric reflector technology for enhanced performance
- Versatile Application: Ideal for applications requiring specific wavelength reflection and transmission in the UV spectrum
Applications
- Spectroscopy: Essential for precise wavelength selection and transmission in spectroscopic studies
- Imaging: Perfect for imaging setups demanding specific wavelength filtering and transmission
- Research: Valuable in scientific research where selective wavelength transmission and reflection are crucial
- Optical Systems: Integral for custom optical systems requiring tailored UV wavelength characteristics
- Laboratory Experiments: Suitable for laboratory experiments demanding controlled UV wavelength interaction
