Apodized FBG
Description
Apodized FBG is a wavelength-reflecting optical device produced by ultraviolet light and phase mask inscription on the optical fiber. It is a basic optical fiber sensing element and is widely used in the fields of optical communication and sensing. AtGrating adopts advanced production technology and Apodized technology to mass produce FBG of various wavelengths in the C+L band, with precise center wavelength, stable performance, high reflectivity, and small 3dB bandwidth.
Apodized FBG
Specifications |
|
|---|---|
| Center Wavelength Range: | 1460-1610nm |
| FBG Length: | From 1mm to 20mm |
| Reflectivity: | <=1% |
| Wavelength Tolerance: | +/-0.5 nm |
| Bandwidth (FWHM): | 0.1~1.2 nm |
| SLSR: | >10 dB |
| FBG Recoating: | None, Acrylate, Polyimide, or custom |
| Tensile Strength: | >100 kpsi |
| Fiber Type: | Single-Mode |
| Fiber Coating: | Acrylate, Polyimide, or custom |
| Pigtail Length: | Standard 1m both ends, or custom |
| Optical Connector: | Bare Fiber, FC/APC, SC/APC, or custom |
Features
- High stability and reliability
- Length customized grating
- Apodized
Applications
- Structural health monitoring
- Energy monitoring
- Bio-Medical sensing
