LDX-3615-885 Multimode Laser Diode 885nm
Description
The LDX-XXXX-885 is a high-power multimode laser diode designed to provide reliable and efficient laser performance at a wavelength of 885nm. This laser diode offers a wide range of output power options, with up to 6000mW in free space and up to 4800mW when used with fiber optics.
It boasts high output power and dynamic range, making it suitable for various applications. Custom packaging, wavelengths, and laser designs are available to meet specific requirements.
LDX-3615-885 Multimode Laser Diode 885nm
Specifications |
|
|---|---|
| Center Wavelength: | 0.885 um |
| Output Power: | 6000 mW |
| Operating Temperature: | 25 °C |
| Threshold Current: | 350 mA |
| Threshold Current: | 4600 mA |
| Operating Voltage: | 2.0 V |
| Beam Divergence (FWHM): | 7 θ// (°) |
| Spectral Width (FWHM): | 2.0 nm |
Features
- Wavelength: 885nm
- Output Power: Up to 6000mW in free space, Up to 4800mW from fiber
- High output power and dynamic range
- High efficiency
- Custom packaging available
- Custom wavelengths and laser designs available
Applications
The LDX-XXXX-885 laser diode is ideal for a wide range of applications, including but not limited to:
- Industrial laser systems
- Medical equipment
- Research and development
- Laser-based manufacturing processes
- Fiber optic communication systems
- Scientific experiments and studies
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2014
Frequently Asked Questions
The wavelength of the LDX-3615-885 laser diode is 885nm.
The LDX-3615-885 laser diode produces 6000mW in free space packages and 4800mW from the fiber in fiber coupled packages.
The LDX-3615-885 laser diode is suitable for diode laser solutions, scientific and industrial applications, and OEM applications.
Yes, custom packaging is available for the LDX-3615-885 laser diode.
Yes, custom wavelengths and laser designs are available for the LDX-3615-885 laser diode.
