Fibolux Customer Specific Fiber Coupled Semiconductor Laser Light Source
Description
Fibotec offers customer specific fiber coupled light sources for the laboratory (single piece prototype) and for industrial applications (modules / subsystems, or private labelled systems). Commercially available diodes are used, such as semiconductor laser diodes, LED, and SLED.
See the Worked Examples in the pdf-datasheet and send in your needs for discussion and approval.
Fibolux Customer Specific Fiber Coupled Semiconductor Laser Light Source
Specifications |
|
|---|---|
| Wavelength: | 300-2500 typ. nm |
| Output Power: | 0,1-10000 typ. mW |
| Fiber Core Diamater: | 3-200 typ. um |
| Fiber Cladding Diameter: | 5-130 typ. um |
Features
- open packages, modules, and instruments
- cw, modulated (analog/digital), and pulsed
- single mode or multimode fiber
- single diode or multiple diodes
- bare fiber, connector or adapter, collimator or focuser
- manual and/or remote operation
Applications
- point sources
- test light sources
- light sources for fiber sensing
- light sources for optical instruments
- light sources for biotech / medical
- thermal printing and 3D printing
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
Germany
-
Sold by:
-
On FindLight:
since 2021
Frequently Asked Questions
Commercially available diodes such as semiconductor laser diodes, LED, and SLED are used.
The fiber can be single mode or multimode.
Yes, the light source can be operated manually and/or remotely.
The light sources can be used as point sources, test light sources, light sources for fiber sensing, light sources for optical instruments, light sources for biotech/medical applications, and for thermal printing and 3D printing.
You can find more information in the pdf-datasheet provided by Fibotec.
