LDX-2310-627: 627nm 280mW Fiber Coupled Multimode Laser Diode
Description
The LDX Series of made-in-the-US, high-power, multimode laser diodes provides wavelengths from 400nm – 1900nm, a wide range of output powers and package types, as well as completely customized solutions. We have been offering these high-quality laser diodes for over 25 years. The performance, reliability, and lifetimes are time-tested, and if, for some reason, there is an issue, we will make it right.
Benefits:
- Low threshold current and high slope efficiency: resulting in a low operating current that enhances reliability
- High precision placement with a flux-free, void-free, uniform solder thickness
- Customizable: From wafers & packaging to options & qualification
- Made-in-the-US: No tariffs or international shipping issues
- Dependable Delivery: Just-in-time deliveries – Buffer stock
- No Discontinued Products: Guaranteed supply for the life of your program
- Advanced hard or soft laser soldering process – Superior packaging
- The broadest selection of diode wavelengths and packaging configurations on the market
LDX-2310-627: 627nm 280mW Fiber Coupled Multimode Laser Diode
Specifications |
|
|---|---|
| Laser Type: | Continuous Wave (CW) |
| Fiber Type: | Multi-Mode |
| Wavelength: | 627 nm |
| Output Power: | 280 mW |
| Fiber Core Diamater: | 105 um |
| Fiber Cladding Diameter: | 125 um |
| Operating Current: | 1500 mA |
Features
- Wavelength: 627nm
- Output Power: 350mW free space, 280mW from the fiber
- High output power and dynamic range
- High efficiency
- Custom packaging available
- Custom wavelengths and laser designs available.
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2014
Frequently Asked Questions
The LDX Series is a range of high-power, multimode laser diodes that provide a wide range of output powers, wavelengths from 400nm – 1900nm, and package types.
The LDX Series laser diodes have a low threshold current and high slope efficiency, resulting in a low operating current that enhances reliability. They also offer customizable options and qualification, are made in the US with no tariffs or international shipping issues, and have just-in-time deliveries with buffer stock.
The LDX-2310-627 laser diode has an output power of 350mW free space and 280mW from the fiber.
Yes, custom packaging and wavelengths are available for the LDX Series laser diodes.
The performance, reliability, and lifetimes of the LDX Series laser diodes are time-tested, and if there is an issue, the company will make it right.
