LDX-3310-915 Multimode Laser Diode 915nm
Description
The LDX Series represents a pinnacle of high-power, multimode laser diodes crafted in the USA. These laser diodes offer an expansive wavelength range from 400nm to 1900nm, encompassing a diverse spectrum of applications.
With over 25 years of experience, we have consistently delivered unmatched performance, unwavering reliability, and extended lifetimes. Rest assured, our commitment ensures that any issue encountered will be promptly addressed to make it right.
LDX-3310-915 Multimode Laser Diode 915nm
Specifications |
|
|---|---|
| Laser Type: | Continuous Wave (CW) |
| Fiber Type: | Multi-Mode |
| Wavelength: | 915 nm |
| Output Power: | 3000 mW |
| Fiber Core Diamater: | 100 um |
| Fiber Cladding Diameter: | 250 um |
| Operating Temperature: | 25 ℃ |
| Threshold Current: | 550 mA |
| Operating Current: | 10000 mA |
| Operating Voltage: | 1.8 V |
| Beam Divergence (FWHM): | 7 θ// (°) |
| Spectral Width FWHM: | 3.0 nm |
Features
- Wide Wavelength Range: Covers wavelengths from 400nm to 1900nm
- High Power Output: Provides high-power laser outputs for various applications
- Customized Solutions: Offers fully customized solutions to meet specific needs
- Proven Performance: Trusted for over 25 years for consistent and reliable performance
- Made in the USA: Manufactured in the United States, avoiding tariffs and international shipping issues
Applications
- Industrial Applications: Ideal for industrial processes such as material processing, cutting, and engraving
- Scientific Research: Used in scientific experiments and research projects requiring high-power lasers
- Medical Equipment: Incorporated into medical devices and equipment for various medical procedures
- Communication Systems: Suitable for optical communication systems and signal transmission
- Customized Solutions: Tailored for specialized applications across multiple industries
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2014
Frequently Asked Questions
The wavelength of the LDX-3310-915 laser diode is 915nm.
The output power of the LDX-3310-915 laser diode is 3000mW in free space packages and 2400mW from the fiber in fiber coupled packages.
The LDX-3310-915 laser diode is suitable for diode laser solutions, scientific and industrial applications, and OEM applications.
Yes, custom packaging is available for the LDX-3310-915 laser diode.
Yes, custom wavelengths and laser designs are available for the LDX-3310-915 laser diode.
