Double Pass Optic Integrated AOM Module for Quantum Optics 632nm 200MHz FAOM-D-632-200-PM

Name: Double Pass Optic Integrated AOM Module for Quantum Optics 632nm 200MHz FAOM-D-632-200-PM
Brand: CSRayzer Optical Technology
Availability: InStock

Description

Using acousto-optic modulator (AOM) to control laser frequency, switch light and generate modulation sideband is a common technical means, which is often used in optical systems of quantum optics, cold atoms, ion traps, quantum calculation and quantum precision measurement. Double Pass acousto-optic modulation is that the laser passes through AOM twice, and the +1st order diffracted light passes through AOM twice to obtain a double modulated laser signal. Optical fiber coupled acousto-optic Double Pass integrated module can realize double modulation of sum and arbitrary laser, and output double modulated Double Pass laser signal. The input and output are optical fiber coupled output, and the wavelength can be customized at 400-1100nm.

Specifications

Center Wavelength:	632 nm
Operational Wavelength Range:	612 – 652 nm
Acoustic Mode:	Longitudinal
Operating Frequency:	200 MHz
Light Polarization:	Linear
Optical Power Density:	Not Specified
Deflection Angle:	Not Specified
Interaction Material:	Tellurium dioxide
-3dB Bandwidth:	60 MHz
Ultrasonic Velocity:	4200 m/s
Insertion Loss:	4.5 dB
Extinction Ratio (Turn On / Off):	22 dB
Extinction Ratio (Turn On / Off):	55 dB
Rise-Time/Fall-Time:	60 ns

Download Data Sheet

Features

High polarization stability

High coupling efficiency

Miniaturized design, small size

Modular design, easy integration

Strong environmental stability

Applications

Cold atomic system

Quantum optics

Lon trap system

Quantum precision measurement system

Quantum computing

Name

Work Email

Organization (recommended)

Your message to supplier

Add to Watchlist (My Watchlist)

Ships from:

China

Sold by:

CSRayzer Optical Technology

On FindLight:

since 2020

Got Questions? Ask Above ▲

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply

Frequently Asked Questions

What is an acousto-optic modulator (AOM) used for?

An acousto-optic modulator (AOM) is used to control laser frequency, switch light, and generate modulation sidebands. It is commonly applied in optical systems for quantum optics, cold atoms, ion traps, quantum computation, and quantum precision measurement.

What is Double Pass acousto-optic modulation?

Double Pass acousto-optic modulation involves the laser passing through the AOM twice. The +1st order diffracted light passes through the AOM twice, resulting in a double modulated laser signal.

What is the advantage of an optical fiber-coupled acousto-optic Double Pass integrated module?

The optical fiber-coupled acousto-optic Double Pass integrated module can achieve double modulation of sum and arbitrary laser, outputting a double modulated Double Pass laser signal. The input and output are fiber-coupled, and the wavelength can be customized between 400-1100nm.

What are the key features of the optical fiber-coupled acousto-optic Double Pass integrated module?

The key features include high polarization stability, high coupling efficiency, miniaturized design, small size, modular design for easy integration, and strong environmental stability.

In which applications is the acousto-optic Double Pass module typically used?

The acousto-optic Double Pass module is typically used in cold atomic systems, quantum optics, ion trap systems, quantum precision measurement systems, and quantum computing.
