Laser Crystal - CTH:YAG
Description
Ho,Cr,Tm:YAG -yttrium aluminium garnet laser crystals doped with chromium,thulium and holmium ions to provide lasing at 2.13 microns are finding more and more applications,especially in the medical industry.The inherent advantage of the crystal crystal is that it employs YAG as the host. YAG’s physical,thermal and optical properties are well known and understood by every laser designer. It has wide applications in surgery, dentistry, atmospheric testing, etc.
Laser Crystal - CTH:YAG
Specifications |
|
|---|---|
| Type Of Crystal: | Yb:KGW |
| Crystal Diameter: | 10 mm |
| Crystal Length: | 100 mm |
| AR Coating: | Both sides |
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
China
-
Sold by:
-
On FindLight:
since 2018
Frequently Asked Questions
Laser Crystal - CTH:YAG is a yttrium aluminium garnet laser crystal doped with chromium, thulium, and holmium ions to provide lasing at 2.13 microns.
The advantages of CTH:YAG include high slope efficiency, can be pumped by flashlamp or diode, operates well at room temperature, and operates in a relatively eye-safe wavelength range.
CTH:YAG has wide applications in surgery, dentistry, atmospheric testing, etc.
The technical parameters of CTH:YAG include wavefront distortion of ≤0.125ʎ/inch@1064nm, rod sizes of diameter: 3-6mm, length: 50-120mm, dimensional tolerances of diameter: ±0.05mm, length: ±0.5mm, and surface quality of 10/5 AR coating reflectivity of ≤0.25%@2094nm.
The concentration of the dopant ions in CTH:YAG is Cr3+ concentration of 0.85%, Tm3+ concentration of 5.9%, and Ho3+ concentration of 0.36%.
