SPM-001-X
Description
The SPM-001-X measures in the ultraviolet, visible, and near-infrared wavelengths and features a proprietary optical design to achieve up to 0.12 nm resolution (SPM-001-M). It also runs on powerful user software based on LabVIEW or easily integrated into existing software using
one of our software development kits.
SPM-001-X
Specifications |
|
|---|---|
| Monochromator Type: | Czerny-Turner |
| Effective Focal Length: | - mm |
| Diffraction Grating: | - lines/mm |
| Grating Blaze Wavelength: | - nm |
| Spectral Range: | 190-1100nm |
| Linear Dispersion (Avg): | - nm/mm |
| Spectral Resolution (Avg): | 0.15 nm |
| Spectral Range: | 190- 1100 nm |
| Blaze Wavelength: | Choice |
| Resolution: | 0.12/0.18 (center/outer) nm |
| Detector: | Toshiba TC1304 |
| Detector Size: | 3648 Pixel Array |
| ADC: | 12 Bit |
Features
The SPM-001-X is fully compatible with the SPL family of light sources,
accessories, software development kits and SpecSoft Pro from Photon
Control.
Applications
N.B. Some applications require additional software that is not included with the SPM-001-X.
Visible Spectrum/ Color Monitoring
Biophotonics
Transmission
Laser/ Light Source Monitoring
Absorption
Ultra-fast Lasers and Laser Tuning
Fluorescence
Molar Concentration
Optical Inspection
Chemical Analysis
Reflection
Scattering
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
Canada
-
Sold by:
-
On FindLight:
since 2016
Frequently Asked Questions
The SPM-001-X is suitable for a variety of applications, including visible spectrum/color monitoring, biophotonics, transmission, laser/light source monitoring, absorption, ultra-fast lasers and laser tuning, fluorescence, molar concentration, optical inspection, chemical analysis, reflection, and scattering.
The SPM-001-X runs on powerful user software based on LabVIEW or easily integrated into existing software using one of our software development kits.
The SPM-001-X features a proprietary optical design to achieve up to 0.12 nm resolution (SPM-001-M).
Yes, some applications require additional software that is not included with the SPM-001-X.
The SPM-001-X measures in the ultraviolet, visible, and near-infrared wavelengths.
